Planetary
Size | 50 | 70 | 90 | 120 | 155 |
---|---|---|---|---|---|
Ratio | 3-100 | 3-100 | 3-100 | 3-100 | 3-100 |
Rated torque [Nm] | 12 | 16 | 43 | 110 | 300 |
Rated torque [in-lb] | 106 | 142 | 381 | 974 | 2,655 |
Output Shaft Diameter [mm] | 12 | 16 | 22 | 32 | 40 |
Output Shaft Diameter [in] | 0.5 | 0.6 | 0.9 | 1.3 | 1.6 |
Size | 50 | 70 | 90 | 120 | 155 |
---|---|---|---|---|---|
Ratio | 3-100 | 3-100 | 3-100 | 3-100 | 3-100 |
Rated torque [Nm] | 12 | 16 | 43 | 110 | 300 |
Rated torque [in-lb] | 106 | 142 | 381 | 974 | 2,655 |
Output Shaft Diameter [mm] | 12 | 16 | 22 | 32 | 40 |
Output Shaft Diameter [in] | 0.5 | 0.6 | 0.9 | 1.3 | 1.6 |
